A typical application for a connector housing is to provide a receptacle for connectors when they are mounted to a printed circuit board.
#3.0mm molex connector series#
The 430 series from Molex features 3.0 mm pitch connector housings, they form part of the unique, compact Micro- Fit connector system.
All components are lead-free, RoHS compliant, halogen-free, and glow wire capable.Product Details Molex Micro-Fit Connector Housings – Series 43025 & 43020 Micro-Fit 3.0 Interconnects are UL recognized, CSA approved and TUV licensed. The housings utilize positive-lock features to prevent accidental disconnects. Contacts are fully isolated on each side of the interface to eliminate potential arcing and incorporate four points of contact for redundancy. Micro-Fit 3.0 Connectors can be purchased in pure tin, or one of two thicknesses of select gold to provide cost savings. Based on a 3.0mm centerline Micro-Fit 3.0 is available in wire-to-wire and wire-to-board configurations, SMT and through-hole processing, 2 to 24 circuits, and single- and dual-row versions. Molex’s Micro-Fit 3.0 Interconnects offer users a low- to mid-range power-distribution solution with the highest current in the smallest footprint available today. Micro-Fit 3.0™ Connectors are a 3.00mm pitch high-density, low-power connector system available in wire-to-wire and wire-to-board configurations with SMT and through-hole options and up to 5.0A to meet low- to mid-range power application needs.
#3.0mm molex connector full#
1Meter, 2Meter 2 core wire length) attached to one side to run to your printer's control board and allow you the ability to connect the other connector over any existing 2 wire component (Fans, Thermistors, Heater Cartridges, etc.) For easy detachment!Ī full range of sizes is available upon request as an official Molex brand Distributor! We have any plug option you require for a nice and tidy wiring job for your machine! Finally, begin to show your printer the love it deserves with nice cable management means! Wiring should no longer be an afterthought, but a well-planned layout! These Molex Connectors combined without OpenBuilds™ brand Premium 2,3, & 4 core wires mean your printer can have a reliable sleek black wired solution to replace Low-quality Chinese wires or to simply finalize your wiring needs for good with 100% reliability rewiring each stepper motor, limit switch, and hotend component from your Control Board to the Motor, Sensor, Fan, and all your extruder & Hotend wiring needs! Never have a failed Thermistor or motor wire again! Let us help you customize your printer's wiring needs with our free Cable Comb Design services that come with the sale of our wires and cable management materials!įor the ultimate in custom wiring solutions and clean wiring builds:Īlso, see our Premium Stepper Motor wiring kits that feature clean insulated 4 core solid black wire to JST connector type that plugs directly into your stepper motor! Clean up that ugly look of the 4 stepper motor wires in a fan or all lose! These also come with colored PET sleeve options to match your printer's look and theme (Black
These connectors once gone bad, or accidentally come detached means there is NO WAY to ever fix your various hotend components that use these very special connectors. However, we will also provide kits that allow any 3D printer builder to use these excellent detachable 2 core wires for any and all of your hotend components to easily detach from your hotend wiring loom! We have finally received permission to distribute the officially licensed connectors (Authorized Distributor - which is part of the reason these are so impossible to ever replace as this validation must be granted to even sell this brand's products!) that no clone can rival the quality and perfect size and ease of use for 3D printer hotend or any part you wish to have a quick detach for! These Molex Connectors are officially known as Molex Micro-Fit 3.0™ Connectors. These connectors are used on most all E3D Hotend components, such as the extruder fan plug, the thermistor cartridge (or Pt100 / PT1000), Part Cooling Fans, and even on Premium Grade (Green Wired With Disconnect 24V) Heater Cartridge. Replacement E3D 2 Wire Molex Connector Set
